Sloped roof - porcelain tile - T-shaped groove track H45
Overview

Mainly suitable for various ceramic or glazed tile roof photovoltaic brackets, professional design enables perfect connection between track components and ceramic tiles. A design scheme tailored to local conditions and excellent structural strength calculation, saving installation time and reducing installation costs; Patented accessory design provides you with a more efficient installation experience.

Product Features
Rectangle
Rectangle
Rectangle

Advantage

Parameter

Adapt to the scene

Advantage
Suitable for different roofs
  • Design according to the specific situation of each customer and flexibly select different bracket components;
Fully compatible with different photovoltaic modules
  • Free and flexible support for various types of photovoltaic modules
Save construction costs and time
  • We will provide you with installation manuals and system solutions, so on-site construction is simple
Parameter
System Name
Sloped Roof - Porcelain Tile - T-shaped Slot Track H45
Installation location
sloping roof
Installation foundation
Porcelain tiles, flat tiles, slate tiles, asphalt tiles, etc
Installation angle
5-45 °
Wind load
60m/s
Snow load
1.6KN/m2
Applicable component types
Framed, frameless
Component layout method
Horizontal, vertical
Standards
AS/NZS 1170, DIN 1055, JIS C8955:2017, International Building Code IBC 2009, California Building Code CBC 2010;
Support material
Q235B (hot-dip galvanized), AI6005-T5 (surface anodized)
Fastener Material
SUS304&Zinc Nickel Alloy&Hot Dip Galvanized
Material of spare parts
AI6005-T5 (surface anodized)
Support color
Natural silver or colored according to customer requirements
System warranty
10 years
