Advantage
Parameter
Adapt to the scene
Advantage
Optional pre installed components to save installation time and cost
- Customers can flexibly customize a variety of pre installed bracket components according to project requirements, and pre install them in the factory without any on-site cutting or drilling, reducing on-site installation time and directly reducing project installation costs.
Comprehensive optimization of structure, with more advantageous prices
- While ensuring the structural strength of the system, the longitudinal beams, crossbeams, columns, and other structures have been further optimized.
Highly pre installed to save installation time
- Less installation of spare parts, highly pre installed in the factory, without the need for any on-site cutting or drilling, reducing the difficulty and time of on-site construction, greatly reducing project costs.
Flexible adjustment of waterproof design on site
- Industry leading professional design, designed according to terrain adjustment, can achieve vertical, east-west, southwest, north-south adjustment, simplify installation, and maximize photovoltaic power generation.
Parameter
Installation location
Ground level
Installation foundation
Cement foundation, spiral ground pile
Installation angle
0-20 °
Applicable component types
Framed, frameless
Component layout method
Horizontal, vertical
Design Standards
AS/NZS 1170, DIN 1055, JIS C8955:2017, International Building Code: IBC 2009, California Building Code: CBC 2010;
Support material
AL6005-T5 (surface anodized)
Fastener material
Zinc nickel alloy&stainless steel SUS304
Material of spare parts
AL6005-T5 (surface anodized)
Support color
Natural silver or colored according to customer requirements
